基于Microsoft.Extensions.AI核心庫實現RAG應用
當前位置:點晴教程→知識管理交流
→『 技術文檔交流 』
大家好,我是Edison。 之前我們了解 Microsoft.Extensions.AI 和 Microsoft.Extensions.VectorData 兩個重要的AI應用核心庫。基于對他們的了解,今天我們就可以來實戰一個RAG問答應用,把之前所學的串起來。 前提知識點:向量存儲、詞嵌入、向量搜索、提示詞工程、函數調用。 案例需求背景假設我們在一家名叫“易速鮮花”的電商網站工作,顧名思義,這是一家從事鮮花電商的網站。我們有一些運營手冊、員工手冊之類的文檔(例如下圖所示的一些pdf文件),想要將其導入知識庫并創建一個AI機器人,負責日常為員工解答一些政策性的問題。 例如,員工想要了解獎勵標準、行為準備、報銷流程等等,都可以通過和這個AI機器人對話就可以快速了解最新的政策和流程。 在接下來的Demo中,我們會使用以下工具: (1) LLM 采用 Qwen2.5-7B-Instruct,可以使用SiliconFlow平臺提供的API,你也可以改為你喜歡的其他模型如DeepSeek,但是建議不要用大炮打蚊子哈。 注冊地址:點此注冊 (2) Qdrant 作為 向量數據庫,可以使用Docker在你本地運行一個: docker run -p 6333:6333 -p 6334:6334 \ -v $(pwd)/qdrant_storage:/qdrant/storage \ qdrant/qdrant (3) Ollama 運行 bge-m3 模型 作為 Emedding生成器,可以自行拉取一個在你本地運行: ollama pull bge-m3 構建你的RAG應用創建一個控制臺應用程序,添加一些必要的文件目錄 和 配置文件,最終的解決方案如下圖所示。 在Documents目錄下放了我們要導入的一些pdf文檔,例如公司運營手冊、員工手冊等等。 在Models目錄下放了一些公用的model類,其中TextSnippet類作為向量存儲的實體類,而TextSearchResult類則作為向量搜索結果的模型類。 (1)TextSnippet 這里我們的TextEmbedding字段就是我們的向量值,它有1024維。 注意:這里的維度是我們自己定義的,你也可以改為你想要的維度數量,但是你的詞嵌入模型需要支持你想要的維度數量。 public sealed class TextSnippet<TKey> { [VectorStoreRecordKey] public required TKey Key { get; set; } [VectorStoreRecordData] public string? Text { get; set; } [VectorStoreRecordData] public string? ReferenceDescription { get; set; } [VectorStoreRecordData] public string? ReferenceLink { get; set; } [VectorStoreRecordVector(Dimensions: 1024)] public ReadOnlyMemory<float> TextEmbedding { get; set; } } (2)TextSearchResult 這個類主要用來返回給LLM做推理用的,我這里只需要三個字段:Value, Link 和 Score 即可。 public class TextSearchResult { public string Value { get; set; } public string? Link { get; set; } public double? Score { get; set; } } (3)RawContent 這個類主要用來在PDF導入時作為一個臨時存儲源數據文檔內容。 public sealed class RawContent { public string? Text { get; init; } public int PageNumber { get; init; } } 在Plugins目錄下放了一些公用的幫助類,如PdfDataLoader可以實現PDF文件的讀取和導入向量數據庫,VectorDataSearcher可以實現根據用戶的query搜索向量數據庫獲取TopN個近似文檔,而UniqueKeyGenerator則用來生成唯一的ID Key。 (1)PdfDataLoader 作為PDF文件的導入核心邏輯,它實現了PDF文檔讀取、切分、生成指定維度的向量 并 存入向量數據庫。 注意:這里只考慮了文本格式的內容,如果你還想考慮文件中的圖片將其轉成文本,你需要增加一個LLM來幫你做圖片轉文本的工作。 public sealed class PdfDataLoader<TKey> where TKey : notnull { private readonly IVectorStoreRecordCollection<TKey, TextSnippet<TKey>> _vectorStoreRecordCollection; private readonly UniqueKeyGenerator<TKey> _uniqueKeyGenerator; private readonly IEmbeddingGenerator<string, Embedding<float>> _embeddingGenerator; public PdfDataLoader( UniqueKeyGenerator<TKey> uniqueKeyGenerator, IVectorStoreRecordCollection<TKey, TextSnippet<TKey>> vectorStoreRecordCollection, IEmbeddingGenerator<string, Embedding<float>> embeddingGenerator) { _vectorStoreRecordCollection = vectorStoreRecordCollection; _uniqueKeyGenerator = uniqueKeyGenerator; _embeddingGenerator = embeddingGenerator; } public async Task LoadPdf(string pdfPath, int batchSize, int betweenBatchDelayInMs) { // Create the collection if it doesn't exist. await _vectorStoreRecordCollection.CreateCollectionIfNotExistsAsync(); // Load the text and images from the PDF file and split them into batches. var sections = LoadAllTexts(pdfPath); var batches = sections.Chunk(batchSize); // Process each batch of content items. foreach (var batch in batches) { // Get text contents var textContentTasks = batch.Select(async content => { if (content.Text != null) return content; return new RawContent { Text = string.Empty, PageNumber = content.PageNumber }; }); var textContent = (await Task.WhenAll(textContentTasks)) .Where(c => !string.IsNullOrEmpty(c.Text)) .ToList(); // Map each paragraph to a TextSnippet and generate an embedding for it. var recordTasks = textContent.Select(async content => new TextSnippet<TKey> { Key = _uniqueKeyGenerator.GenerateKey(), Text = content.Text, ReferenceDescription = $"{new FileInfo(pdfPath).Name}#page={content.PageNumber}", ReferenceLink = $"{new Uri(new FileInfo(pdfPath).FullName).AbsoluteUri}#page={content.PageNumber}", TextEmbedding = await _embeddingGenerator.GenerateEmbeddingVectorAsync(content.Text!) }); // Upsert the records into the vector store. var records = await Task.WhenAll(recordTasks); var upsertedKeys = _vectorStoreRecordCollection.UpsertBatchAsync(records); await foreach (var key in upsertedKeys) { Console.WriteLine($"Upserted record '{key}' into VectorDB"); } await Task.Delay(betweenBatchDelayInMs); } } private static IEnumerable<RawContent> LoadAllTexts(string pdfPath) { using (PdfDocument document = PdfDocument.Open(pdfPath)) { foreach (Page page in document.GetPages()) { var blocks = DefaultPageSegmenter.Instance.GetBlocks(page.GetWords()); foreach (var block in blocks) yield return new RawContent { Text = block.Text, PageNumber = page.Number }; } } } } (2)VectorDataSearcher 和上一篇文章介紹的內容類似,主要做語義搜索,獲取TopN個近似內容。 public class VectorDataSearcher<TKey> where TKey : notnull { private readonly IVectorStoreRecordCollection<TKey, TextSnippet<TKey>> _vectorStoreRecordCollection; private readonly IEmbeddingGenerator<string, Embedding<float>> _embeddingGenerator; public VectorDataSearcher(IVectorStoreRecordCollection<TKey, TextSnippet<TKey>> vectorStoreRecordCollection, IEmbeddingGenerator<string, Embedding<float>> embeddingGenerator) { _vectorStoreRecordCollection = vectorStoreRecordCollection; _embeddingGenerator = embeddingGenerator; } [Description("Get top N text search results from vector store by user's query (N is 1 by default)")] [return: Description("Collection of text search result")] public async Task<IEnumerable<TextSearchResult>> GetTextSearchResults(string query, int topN = 1) { var queryEmbedding = await _embeddingGenerator.GenerateEmbeddingVectorAsync(query); // Query from vector data store var searchOptions = new VectorSearchOptions() { Top = topN, VectorPropertyName = nameof(TextSnippet<TKey>.TextEmbedding) }; var searchResults = await _vectorStoreRecordCollection.VectorizedSearchAsync(queryEmbedding, searchOptions); var responseResults = new List<TextSearchResult>(); await foreach (var result in searchResults.Results) { responseResults.Add(new TextSearchResult() { Value = result.Record.Text ?? string.Empty, Link = result.Record.ReferenceLink ?? string.Empty, Score = result.Score }); } return responseResults; } } (3)UniqueKeyGenerator 這個主要是一個代理,后續我們主要使用Guid作為Key。 public sealed class UniqueKeyGenerator<TKey>(Func<TKey> generator) where TKey : notnull { /// <summary> /// Generate a unique key. /// </summary> /// <returns>The unique key that was generated.</returns> public TKey GenerateKey() => generator(); } 串聯實現RAG問答安裝NuGet包: Microsoft.Extensions.AI (preview) Microsoft.Extensions.Ollama (preivew) Microsoft.Extensions.AI.OpenAI (preivew) Microsoft.Extensions.VectorData.Abstractions (preivew) Microsoft.SemanticKernel.Connectors.Qdrant (preivew) PdfPig (0.1.9) Microsoft.Extensions.Configuration (8.0.0) Microsoft.Extensions.Configuration.Json (8.0.0) 下面我們分解幾個核心步驟來實現RAG問答。 Step1. 配置文件appsettings.json: { "LLM": { "EndPoint": "https://api.siliconflow.cn", "ApiKey": "sk-**********************", // Replace with your ApiKey "ModelId": "Qwen/Qwen2.5-7B-Instruct" }, "Embeddings": { "Ollama": { "EndPoint": "http://localhost:11434", "ModelId": "bge-m3" } }, "VectorStores": { "Qdrant": { "Host": "edt-dev-server", "Port": 6334, "ApiKey": "EdisonTalk@2025" } }, "RAG": { "CollectionName": "oneflower", "DataLoadingBatchSize": 10, "DataLoadingBetweenBatchDelayInMilliseconds": 1000, "PdfFileFolder": "Documents" } } Step2. 加載配置: var config = new ConfigurationBuilder() .AddJsonFile($"appsettings.json") .Build(); Step3. 初始化ChatClient、Embedding生成器 以及 VectorStore: # ChatClient var apiKeyCredential = new ApiKeyCredential(config["LLM:ApiKey"]); var aiClientOptions = new OpenAIClientOptions(); aiClientOptions.Endpoint = new Uri(config["LLM:EndPoint"]); var aiClient = new OpenAIClient(apiKeyCredential, aiClientOptions) .AsChatClient(config["LLM:ModelId"]); var chatClient = new ChatClientBuilder(aiClient) .UseFunctionInvocation() .Build(); # EmbeddingGenerator var embedingGenerator = new OllamaEmbeddingGenerator(new Uri(config["Embeddings:Ollama:EndPoint"]), config["Embeddings:Ollama:ModelId"]); # VectorStore var vectorStore = new QdrantVectorStore(new QdrantClient(host: config["VectorStores:Qdrant:Host"], port: int.Parse(config["VectorStores:Qdrant:Port"]), apiKey: config["VectorStores:Qdrant:ApiKey"])); Step4. 導入PDF文檔到VectorStore: var ragConfig = config.GetSection("RAG"); // Get the unique key genrator var uniqueKeyGenerator = new UniqueKeyGenerator<Guid>(() => Guid.NewGuid()); // Get the collection in qdrant var ragVectorRecordCollection = vectorStore.GetCollection<Guid, TextSnippet<Guid>>(ragConfig["CollectionName"]); // Get the PDF loader var pdfLoader = new PdfDataLoader<Guid>(uniqueKeyGenerator, ragVectorRecordCollection, embedingGenerator); // Start to load PDF to VectorStore var pdfFilePath = ragConfig["PdfFileFolder"]; var pdfFiles = Directory.GetFiles(pdfFilePath); try { foreach (var pdfFile in pdfFiles) { Console.WriteLine($"[LOG] Start Loading PDF into vector store: {pdfFile}"); await pdfLoader.LoadPdf( pdfFile, int.Parse(ragConfig["DataLoadingBatchSize"]), int.Parse(ragConfig["DataLoadingBetweenBatchDelayInMilliseconds"])); Console.WriteLine($"[LOG] Finished Loading PDF into vector store: {pdfFile}"); } Console.WriteLine($"[LOG] All PDFs loaded into vector store succeed!"); } catch (Exception ex) { Console.WriteLine($"[ERROR] Failed to load PDFs: {ex.Message}"); return; } Step5. 構建AI對話機器人: 重點關注這里的提示詞模板,我們做了幾件事情: (1)給AI設定一個人設:鮮花網站的AI對話機器人,告知其負責的職責。 (2)告訴AI要使用相關工具(向量搜索插件)進行相關背景信息的搜索獲取,然后將結果 連同 用戶的問題 組成一個新的提示詞,最后將這個新的提示詞發給大模型進行處理。 (3)告訴AI在輸出信息時要把引用的文檔信息鏈接也一同輸出。 Console.WriteLine("[LOG] Now starting the chatting window for you..."); Console.ForegroundColor = ConsoleColor.Green; var promptTemplate = """ 你是一個專業的AI聊天機器人,為易速鮮花網站的所有員工提供信息咨詢服務。 請使用下面的提示使用工具從向量數據庫中獲取相關信息來回答用戶提出的問題: {{#with (SearchPlugin-GetTextSearchResults question)}} {{#each this}} Value: {{Value}} Link: {{Link}} Score: {{Score}} ----------------- {{/each}} {{/with}} 輸出要求:請?jiān)诨貜?fù)中引用相關信息的地方包括對相關信息的引用。 用戶問題: {{question}} """; var history = new List<ChatMessage>(); var vectorSearchTool = new VectorDataSearcher<Guid>(ragVectorRecordCollection, embedingGenerator); var chatOptions = new ChatOptions() { Tools = [ AIFunctionFactory.Create(vectorSearchTool.GetTextSearchResults) ] }; // Prompt the user for a question. Console.ForegroundColor = ConsoleColor.Green; Console.WriteLine($"助手> 今天有什么可以幫到你的?"); while (true) { // Read the user question. Console.ForegroundColor = ConsoleColor.White; Console.Write("用戶> "); var question = Console.ReadLine(); // Exit the application if the user didn't type anything. if (!string.IsNullOrWhiteSpace(question) && question.ToUpper() == "EXIT") break; var ragPrompt = promptTemplate.Replace("{question}", question); history.Add(new ChatMessage(ChatRole.User, ragPrompt)); Console.ForegroundColor = ConsoleColor.Green; Console.Write("助手> "); var result = await chatClient.GetResponseAsync(history, chatOptions); 調試驗證首先,看看PDF導入中的log顯示: 其次,驗證下Qdrant中是否新增了導入的PDF文檔數據: 最后,和AI機器人對話咨詢問題: 問題1及其回復: 問題2及其回復: 更多的問題,就留給你去調戲了。 小結本文介紹了如何基于Microsoft.Extensions.AI + Microsoft.Extensions.VectorData 一步一步地實現一個RAG(檢索增強生成)應用,相信會對你有所幫助。 如果你也是.NET程序員希望參與AI應用的開發,那就快快了解和使用基于Microsoft.Extensioins.AI + Microsoft.Extensions.VectorData 的生態組件庫吧。 示例源碼GitHub:點此查看 轉自https://www.cnblogs.com/edisonchou/p/-/introduction-to-vector-rag-demo 該文章在 2025/3/10 9:41:31 編輯過 |
